Quick Details
Model Number:8/6E-A H(R)
Place of Origin:Shanodng , China
Application:Industrial Utilities, Irrigation and Agriculture, Marine, Metal and Equipment Manufacturers, Mining industry
Horsepower:Depending on the model
Power Source:Electric
Pressure:Depending on the model
Structure:Single-stage Pump
Outlet Size:Depending on the model
Voltage:Depending on the model
Power:Depending on the model, 18.5-115kw
Product name:Sand Pump
Type:Horizontal centrifugal Pump
Model:8/6E-A H(R)
Capacity:126-648m3/h
Head:10-48m
Speed:500-1000r/min
After sale Service:Life-long Service
Usage:Handling abrasive or corrosive slurry in many industries
Fuel:Diesel or Electric
Supply Ability
Supply Ability:200 Set/Sets per Month Slurry Pumps
Packaging & Delivery
Packaging Details:Standard packing, Seaworthy packing, or as required
Port:Qingdao
Lead Time :
| Quantity(Sets) | 1 – 3 | >3 |
| Est. Time(days) | 10 | To be negotiated |
Product Description
The series of slurry pump product has rational structure, high efficiency, reliable operation, convenient maintenance and other advantages, and is widely used for conveying abrasive or corrosive slurry, especially clinker of power plants in electric power, metallurgy, mining, coal, building materials, chemical industry and other industrial sectors.
1. It uses modern CAD design method, and has excellent hydraulic performance, high efficiency, and low wear rate;
2. It has wide runner, good anti-clogging performance, and excellent cavitation performance;
3. It uses expeller and filler combined seal and mechanical seal, ensuring that the slurry doesn’t leak;
4. The reliability design greatly improves mean time between failures (MTBF) of complete machine;
5. It uses thin oil lubrication metric bearing, and rationally sets lubrication and cooling system to ensure that the bearing operates at low temperature;
6. Flow passage components are made of special materials, so they have good wear resistance and corrosive resistance; after special processing, they are used for seawater dusting, and seawater and salt mist electrochemical corrosion conditions;
7. In allowable pressure range, it can be used in series in stages, and allowable maximum working pressure is 3.6Mpa.
