Controlair Valve R431002639/H-2-X
– Version H-2, OUT port – delivers increasing pressure in direct proportion to clockwise lever
travel from minimum pressure position (facing lever side of valve).
– Qn = 900 l/min
– Actuating element Lever
– Internal thread
– Poppet valve
– H-2-X H-2-FX H-2-LX
Type Poppet valve
Working pressure min./max. 0.1 … 14 bar
Adjustment range min./max. See table below
Ambient temperature min./max. -40 … 70 °C
Medium temperature min./max. -40 … 70 °C
Medium Compressed air
Nominal flow Qn 900 l/min
Hysteresis 0.07 bar
Weight 2.5 kg
